R55310-10 / R55310-11 / R55310-B30 / R55310-S30
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Case Version
Base Plated Version
Horizontal Version Vertical Version
|
35(52) µH
81(168) µH
220(330) µH
|
8.0
6.0
4.0
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
The core has too low losses.
|
R55930-10 / R55930-11 / R55930-S40
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Base Plated Version
Horizontal Version Vertical Version
|
40(50) µH
120(290) µH
240(460) µH
|
10.0
7.0
5.0
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
The core has too low losses.
|
R55548-10 / R55548-11 / R55548-S50
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Base Plated Version
Horizontal Version Vertical Version
|
110(195) µH
450(630) µH
530(700) µH
700(1000) µH
|
8.0
3.5
3.0
2.5
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
The core has too low losses.
|
STORAGE CHOKES
