R3311D10 / R3311D11 / R3311DB44 / R3311DB50 / R3311DS50
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Case Version
Base Plated Version
Horizontal Version Vertical Version
|
50(65) µH
110(140) µH
200(280) µH
300(420) µH
500(700) µH
900(1200) µH
|
10.0
8.0
6.0
5.0
4.0
2.5
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
Handwound Versions available for higher currents.
|
R4014D10 / R4014D11 / R4014DB50rund
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Case Version
Horizontal Version Vertical Version
|
100(145) µH
280(475) µH
450(750) µH
650(1100) µH
|
10.0
8.0
6.0
5.0
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
Handwound Versions available for higher currents.
|
R4718D10 / R4718D11 / R4718DB60
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Case Version
Horizontal Version Vertical Version
|
90(160) µH
120(220) µH
260(450) µH
|
20.0
15.0
10.0
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
|
STORAGE CHOKES
