R2006D10 / R2006D11 / R2006DS11 / R2006DB3 / R2006DB28 / R2006DB30 / R2006DS30
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Horizontal Version Vertical Version Base Plated Version Case Version
|
50(65) µH
100(140) µH
200(265) µH
500(760) µH
800(980) µH
|
4.0
3.0
2.5
1.5
1.0
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
Models between 500µH and 800µH available in case versions only.
|
R2408D10 / R2408D11 / R2408DB4 / R2408DB40 / R2408DS30
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Horizontal Version Vertical Version Base Plated Version Case Version
|
100(130) µH
220(300) µH
330(470) µH
450(570) µH
|
4.0
3.0
2.6
2.0
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
|
R2711D10 / R2711D11 / R2711DB4 / R2711DB34 / R2711DB40 / R2711DS40
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Case Version
Base Plated Version
Horizontal Version Vertical Version
|
50(60) µH
100(135) µH
200(265) µH
350(470) µH
500(610) µH
1.0(1.6) mH
|
6.0
5.0
4.0
3.0
2.5
2.0
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
Models between 500µH and 1mH available in case Versions only.
Handwound Versions available for higher currents.
|
STORAGE CHOKES
