STORAGE CHOKES
R1003D10/R1003D11/R1003DB5 / R1003DB6 / R1003DS11/ R1003D-SMD
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
SMD Version Horizontal Version Vertical Version Base Plated Version Case Version
|
25(28) µH
47(53) µH
100(107) µH
220(250) µH
470(550) µH
|
1.0
0.8
0.6
0.5
0.3
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
|
R1305D10 / R1305D11 / R1305DS11 / R1305DB1 / R1305DB7 / R1305DB8 / R1305DB9 / R1305DB10 / R1305FB71 / R1305DKS
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Horizontal Version Vertical Version Base Plated Version Case Version
|
33(36) µH 50(59) µH
100(120) µH
220(270) µH
470(600) µH
680(780) µH
1.0(1.2) mH
|
2.5
2.0
1.5
1.0
0.6
0.4
0.2
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
Models between 500µH and 1mH available in case versions only. Handwound versions available for higher currents.
|
R1705D10 / R1705D11 / R1705DS11 / R1705DB2 / R1705DB26
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Horizontal Version Vertical Version Base Plated Version Case Version
|
50(63) µH
100(120) µH
220(280) µH
470(600) µH
680(900) µH
1.0(1.2) mH
|
3.0
2.0
1.6
1.0
0.8
0.5
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
Models between 680µH and 1,0mH available in case versions only.
|
