>> Manufacturing of inductive
components
components
>> Your solution partner in EMC
R5114D10 / R5114D11
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Horizontal Version Vertical Version
|
125(225) µH
4.7(6.1) mH
|
13.0
1.5
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
|
R5128DB70
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Case Version
|
470(630) µH
7.0(9.3) mH
|
6.0
2.0
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
|
R55050-10 / R55050-11 / R55050-B1
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Case Version
Horizontal Version Vertical Version
|
22(27) µH
28(33) µH
60(68) µH
125(200) µH
|
3.2
2.5
2.0
1.5
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
The core has too low losses
|
R55120-10 / R55120-11
|
|||
Versions
|
Inductance
|
Current/A
|
Notes
|
Horizontal Version Vertical Version
|
12(15) µH
120(200) µH
180(330) µH
320(480) µH
|
6.0
3.0
2.5
1.6
|
Defined values are the rated inductances, and the values in brackets are the inductance with no load.
The core has too low losses
|
STORAGE CHOKES
